Core Sensors CS51 Non-Incendive Low Pressure Transducer

The Core Sensors CS51 non-incendive low pressure transducer is designed for measurements of liquids and gases in Class 1, Division 2 locations. It features reverse polarity, EMI protection and an all-welded stainless steel construction for a minimum IP65 rating. The CS51 is an excellent solution for operation in some of the harshest conditions.

Core Sensors CS51 Non-Incendive Low Pressure Transducer Applications
Natural gas compression
Vapor recovery
Process controls

Features

• Pressures from 1 to 49 psi
• Accuracy:
  • ≤ ±0.25% BFSL
  • ≤ ±0.5% BFSL (2 psi and below)
• ≤ ±0.25% of full scale stability
• 100 million pressure cycles
• 2x minimum overpressure
• 5x or 245 psi (whichever is less) burst pressure
• Operating temperature:
  • -40 to 176°F (-40 to 80°C)
  • -4 to 176°F (-20 to 80°C) (electrical connection option F)
• Media temperature:
  • -40 to 257°F (-40 to 125°C)
  • -40 to 221°F (-40 to 105°C) (electrical connection option F)
• TC Zero:
  • ≤ ±1% of full scale
  • ≤ ±2% of full scale (2 psi and below)
• TC Span:
  • ≤ ±1% of full scale
  • ≤ ±2% of full scale (2 PSI and below)
• EMI/RFI protection
• IP65 rating
